Description

Product details U/UTP 4Pairs cable-category5E-PVC Sheath 1000ft (305m) Specifications Category: U/UTP CAT5E-4P- PVC-CM Test Standard Test Standard: ISO/IEC11801, TIA-568-C.2 YD/T1019 Conductor Material: Solid-Bare Copper Nom.O.D.(mm): 0.500 up +0.005 down -0.005 Insulation Material: HDPE Diameter: 0.88?0.03mm Sheath Thickness: 0.50?0.05 mm External O.D.: 5.0?0.4 mm Surface: Clean,Frap,Satiation Material: PVC(complies RoHS),CM Color: Multiple Core Color Core Color: 1 White- Blue /Blue 2 White-Orange /Orange 3 White- Green /Green 4 White- Brown /Brown Packing Packing: Carton Sheath Physical Before Aging Tensile Strength (Mpa): >13.5 Elongation(%): >150 After Aging Tensile Strength(Mpa) : >12.5 Elongation(%): >125 Cold bend: -20/2C 4h Electrical 1.0-250.0MHz Impedance ((O): 100/15 1.0-250.0MHz Delay Skew (ns/100m): <45 DC Resistance (O/100m) max: 9.5 DC Conductor Resistance Unbalance (%) max: 5.0 Ambient temperature Ambient temperature: -20C – 75C
